Epson TM-P20II Wireless Portable Receipt Printer (USB + Bluetooth)

Designed with wearability in mind, the compact Epson TM-P20II portable receipt printer is the ideal solution for on-the-go printing with its long battery life and multiple connectivity options.

  • CO-W01 Projector

Key Features

Durable and reliable 50mm (2inches) portable printer for on-the-go printing

Designed with wearability in mind, the compact Epson TM-P20II portable receipt printer is the ideal solution for on-the-go printing with its long battery life and multiple connectivity options. With high impact protection, conforming to Ingress Protection 54 (IP54) standard for dust and liquid resistance, the portable printer is built to withstand harsh environments, ideal for outdoor work in adverse conditions.

  • Built for harsh environment with high impact protection, dust, and liquid resistance

  • Print speed up to 100 mm/sec

  • Supports USB and Bluetooth connectivity

  • Built for outdoor usage with long battery life of up to 47 hours

  • Compact ergonomic design for the better user experience

Technical Specifications

  • Power Specifications:Battery Life: Bluetooth: 27 Hrs
    Charging Rating: 5V - 3A: 3 Hrs (10 - 30ºC), 6 Hrs (0 - 10ºC); 5V - 1.5A: 4 Hrs (10 - 30ºC), 8 Hrs (0 - 10ºC); 5V - 900/500mA: 7 Hrs (10 - 30ºC), 14 Hrs (0 - 10ºC)

    LED Indicators:Blue LED - Power, Battery Level, Interfaces (Bluetooth)
    Orange LED - Error, Battery Charging

    Built-in Feature:Paper Reduction, Status Notification, Server Direct Print

    Utility Tools:TM Utility (Android, iOS), TM-P20II/TM-P80II Utility (Windows PC), TM-Print Assistant (Android, iOS), Deployment Tool, Monitoring Tool, Epson WebConfig, TM Bluetooth Connector, Firmware Updater, BmpToRaster, ePOS-Print

  • Font:

    ANK: 12 x 24 / 9 x 24 (default) / 9 x 17 / 10 x 24 / 8 x 16;
    Kanji Font:

    24 x 24 / 20 x 24 / 16 x 16;
    Special Font: 12 x 24 / 9 x 24;
    India Font: Width x 32 / Width x 24

    Character Set:

    95 Alphanumeric, 18 set International, 128 x 43 graphics

    Barcode Standards:

    Bar code: UPC-A, UPC-E, JAN8, EAN8, JAN13, EAN13, ITF, Codabar(NW-7), Code39, Code93, Code128, GS1-128, GS1 DataBar
    2D Symbol: PDF417, QR code, Maxi Code, Data Matrix, Aztec, Two-dimensional GS1 DataBar, Composite Symbology

  • Data Buffer:

    Bluetooth: 64 KB

  • Overall Dimensions (D x W x H):

    120 x 79 x 46 mm

  • Dot / Line:

    384 dots

  • Data Buffer

    64 kB

  • Colour:

    Epson Black (EBCK)

  • Printing Method:

    Thermal Line Printing

  • Standard Accessories ROM:

    Roll Paper x 1 Roll (For Checking the Initial Movement of the Printer), CD-ROM (Drivers, Utility software, Manuals), Setup guide, Battery, Printer Charger, Belt Clip

  • Roll paper:58 mm (57.5 ± 0.5 mm) × Dia. 18 - 40 mm
