EB-760Wi Projector
Agile USTi laser display
Key Features
Interactive HD display for any room 53-100" UST display for unrestricted viewing (no shadows/reflections)
Bright and energy efficient laser 4,100lm CLO with 3LCD technology for brighter colours at only 205W
Effortless connectivity options Auto-on, wired / wireless display with USB 2A output for smart sticks
Simple to use and built to last Virtually maintenance free with 5-year, 12,000hr warranty
Document camera compatibility Create and record a live, totally immersive lesson or presentation
Tech Specs
The product features and specifications are subject to change without prior notice
-
Projection System
3LCD Technology, RGB liquid crystal shutter
LCD Panel
0,59 inch with C2 Fine
-
Color Light Output
4.100 Lumen- 2.800 Lumen (economy) In accordance with IDMS15.4
White Light Output
4.100 Lumen - 2.800 Lumen (economy) In accordance with ISO 21118:2020
Resolution
WXGA
Resolution Enhancement
HD ready
Aspect Ratio
16:10
Contrast Ratio
Over 5.000.000 : 1
Light source
Laser
Laser Light source
20.000 hours Durability High, 30.000 hours Durability Eco
Keystone Correction
Manual vertical: ±3 °, Manual horizontal ±3 °
Colour Video Processing
10 Bits
2D Vertical Refresh Rate
100 Hz - 120 Hz
Colour Reproduction
Upto 1.07 billion colours
-
Throw Ratio
0,27 - 0,37:1
Zoom
Digital, Factor:1 - 1,35
Lens
Optical
Screen Size
53 inches - 100 inches
Projection Lens F Number
1,6
Projection Lens Focal Length
3,7 mm
Projection Lens Focus
Manual
Offset
6 : 1
-
Interfaces
USB 2.0-A (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), USB 2.0 Type B (Service Only) (2x), Wi-Fi Direct, Microphone input
Epson iProjection App
Ad-Hoc / Infrastructure
Network Protocol
HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
-
Security
Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Other features
A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Dual Pen Support, Easy OSD pre-setting, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, Instant on/off, Interactive, Interactive Home Screen, Interactive OSD menu, JPEG Viewer, Long light source life, Mail notification function, Microphone input, Network administration, Network projection, OSD copy function, PC Free, PC Interactive, PC free annotation, Power on button, Projection App for Chromebook, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Web Control, Web Remote, Whiteboard sharing function, Wireless LAN capable, iProjection App, iProjecton set-up by scanning a code
Interactivity
Yes - pen and finger-touch
Video Color Modes
Blackboard, Cinema, Dynamic, Presentation, sRGB
Projector control
via: Crestron Integrated Partner, Crestron RoomView, Extron IP Link, AMX Device Discovery, Control4 Simple Device Discovery Protocol
-
Power consumption
197 Watt (Normal On-Mode), 141 Watt (Eco On-Mode), 263 Watt (Normal Peak-mode), 199 Watt (Eco Peak-Mode), 0,5 Watt (Energy saving standby)
Heat Dissipation
895 BTU/hour (max)
Supply Voltage
AC 100 V - 240 V, 50 Hz - 60 Hz
Product dimensions
356‎ x 395 x 133 mm (Width x Depth x Height)
Product weight
6 kg
Noise Level
Normal:37 dB (A) - Economy:27 dB (A)
Supported Temperature
Storage -10° C - 60° C
Supported Humidity
Operation 20% - 80%, Storage 10% - 90%
Improper installation of the projector on a ceiling or wall may cause it to fall, leading to potential injury or damage. To prevent this, ensure the ceiling mount is securely fastened using all mounting points specified in the projector’s user guide which is available to download from our support website (www.epson.eu/support). We recommend the use of Epson-approved ceiling mounts that are compatible with the projector model. Additionally, attach a safety wire of adequate strength to secure the projector to the ceiling mount.
If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.
We recommend that the equipment be inspected on a regular basis, either by the user or by a qualified professional, to ensure continued safe operation.
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.Included Software
Easy Interactive Tools, EasyMP Multi PC Projection, Epson Classroom Connect, Epson Projector Management
Options
Air filter, Ceiling mount, Connection and control box, External Speaker, Finger Touch Unit, Finger Touch Unit Wall Bracket, Pen tip(Felt), Pen tip(Teflon), Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
-
Warranty
60 months Carry in or 12.000 h
-
-
