Bright XGA display solution
The EB-E24 is an affordable and flexible lamp display offering high quality displays with brightness up to 3,600 lumens and display sizes up to 350", as well as quick set-up and a lightweight, portable design. It is highly reliable, easy to maintain and comes with a 3-year warranty.
Key Features
High-quality bright images Deliver bright, crisp, clear images with a scalable screen size up to 350'' offered with a brightness of 3600 lumens output and 3LCD Technology.
Easy connectivity Connect easily with HDMI, VGA, audio, and more. No worry about direct power off, plus a built-in lens shutter for quick pack-up and portability.
Fast display adjustment with Epson's slide keystone Adjust the size of your display fast with Epson's unique Slide Keystone technology. ±30° horizontal slide keystone for easy and fast setup.
Portable and versatile design Lightweight and compact, this display is perfect for various spaces features a built-in speaker for easy setup.
Reliability and durability Peace of mind combined with high reliability and a lamp life of 12,000 hours eco mode), the EB-E24 is backed by a 3-year warranty.
Tech Specs
The product features and specifications are subject to change without prior notice
-
Projection System
3LCD Technology, RGB liquid crystal shutter
LCD Panel
0,55 inch with C2 Fine
-
Color Light Output
3.600 Lumen- 2.100 Lumen (economy) In accordance with IDMS15.4
White Light Output
3.600 Lumen - 2.100 Lumen (economy) In accordance with ISO 21118:2020
Resolution
XGA
Aspect Ratio
4:3
Contrast Ratio
15.000 : 1
Light source
Lamp
Lamp
UHE, 210 W, 6.000 h durability, 12.000 h durability (economy mode)
Colour Video Processing
10 Bits
Colour Reproduction
Upto 1.07 billion colours
-
Throw Ratio
1,44 - 2,88:1
Zoom
Digital, Factor:1 - 2
Screen Size
30 inches - 350 inches
Projection Distance Wide
0,9 m - 10,3 m
Projection Distance Tele
0,9 m - 10,3 m
Projection Lens F Number
1,44
Projection Lens Focal Length
16,7 mm
Projection Lens Focus
Manual
Offset
8 : 1
-
Interfaces
USB 2.0 Type B (Service Only), RS-232C, VGA in (2x), VGA out, HDMI in, Composite in, Jack plug out, Jack plug in (2x), Cinch audio in -
Security
Kensington lock, Padlock, Security cable hole, Password protection
Other features
A/V mute, AV Mute Slide, Auto Power On, Auto source search, Built-in speaker, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Home Screen, Long lamp life, Quick Corner, Split-Screen-Function, Volume control
Video Color Modes
Blackboard, Cinema, Dynamic, Presentation, sRGB
-
Power consumption
284 Watt (Normal On-Mode), 181 Watt (Eco On-Mode), 332 Watt (Normal Peak-mode), 231 Watt (Eco Peak-Mode), 0,3 Watt (Energy saving standby)
Supply Voltage
AC 100 V - 240 V, 50 Hz - 60 Hz
Product dimensions
302 x 249 x 92 mm (Width x Depth x Height)
Product weight
2,7 kg
Noise Level
Normal:37 dB (A) - Economy:28 dB (A)
Supported Temperature
Storage -10° C - 60° C
Supported Humidity
Storage 10% - 90%
Options
Air filter, Ceiling mount, Document camera, External Speaker, Safety wire set, Soft carry case, Spare lamp, Suspension adapter
Loudspeaker
5 Watt
Room Type / Application
Huddle space / Portable, Meeting room / Classroom
Positioning
Ceiling Mounted, Desktop
Color
White
-
Warranty
36 months Carry in, Lamp: 36 months or 1.000 h (whichever comes first)
