EB-FH54 Full HD, 4100 lumens wireless display
The ultimate Full HD collaborative wireless projector
Key Features
Bright and fast, meets big and flexible Full HD, 4100 lumens brightness projector combined with 3LCD technology provides superior image quality and high engagement with a scalable display size up to 304".
Multi-device sharing The Epson iProjection app connects and controls up to 4 devices, with a split-screen feature to display 2 image sources, eliminating the need for an extra projector.
Portable and versatile design Lightweight and compact, this display is perfect for various spaces features a built-in speaker for easy setup.
Instant image correction Auto Vertical Keystone instantly detects and corrects image distortion as you adjust the height with the foot lever, streamlining setup and saving valuable time.
Instant connectivity with Apple AirPlay 2 and Miracast1 Seamlessly share content from laptops, tablets, and smartphones - perfect for BYOD setups and collaborative environments.
Reliability and peace of mind With Epson's trusted reliability, EB-FH54 offers a 3-year warranty with a long lamp life (12,000 hours in Eco mode), giving you continued usage time, after time.
Tech Specs
The product features and specifications are subject to change without prior notice
-
Projection System
3LCD Technology, RGB liquid crystal shutter
LCD Panel
0,62 inch with C2 Fine
-
Color Light Output
4.100 Lumen- 2.300 Lumen (economy) In accordance with IDMS15.4
White Light Output
4.100 Lumen - 2.300 Lumen (economy) In accordance with ISO 21118:2020
Resolution
1080p
Aspect Ratio
16:9
Contrast Ratio
16.000 : 1
Light source
Lamp
Lamp
UHE, 230 W, 5.500 h durability, 12.000 h durability (economy mode)
Keystone Correction
Auto vertical: ±30 °
Colour Video Processing
8 Bits
Colour Reproduction
16.77 million colours
-
Throw Ratio
1,30 - 2,09:1
Zoom
Manual, Factor:1 - 1,62
Screen Size
31 inches - 304 inches
Projection Distance Wide
0,9 m - 8,9 m
Projection Distance Tele
1,4 m - 14,3 m
Projection Distance Wide/Tele
0,88 m - 14,29 m
Projection Lens F Number
1,51 - 1,77
Projection Lens Focal Length
18,2 mm - 29,1 mm
Projection Lens Focus
Manual
Offset
10 : 1
-
Interfaces
USB 2.0-A, USB 2.0 Type B (Service Only), Wireless LAN IEEE 802.11a/b/g/n/ac, HDMI in (2x), Miracast, Jack plug out, Apple AirPlay 2
Network Protocol
HTTPS, IPv6, SNMP
-
Security
Kensington lock, Padlock, Security cable hole, Password protection
Other features
A/V mute, AV Mute Slide, Auto Power On, Auto source search, Built-in speaker, Customizable user logo, Direct Power on/off, Document Camera Compatible, Home Screen, JPEG Viewer, Long lamp life, OSD copy function, PC Free, Quick Corner, Schedule Function, Screen Mirroring, Volume control, Web Control, Web Remote, Wireless LAN capable, iProjection App
Video Color Modes
Blackboard, Cinema, Dynamic, Presentation, sRGB
-
Power consumption
284 Watt (Normal On-Mode), 181 Watt (Eco On-Mode), 332 Watt (Normal Peak-mode), 231 Watt (Eco Peak-Mode), 0,3 Watt (Energy saving standby)
Supply Voltage
AC 100 V - 240 V, 50 Hz - 60 Hz
Product dimensions
309 x 293 x 105 mm (Width x Depth x Height)
Product weight
3,1 kg
Noise Level
Normal:37 dB (A) - Economy:28 dB (A)
Supported Temperature
Storage -10° C - 60° C
Supported Humidity
Storage 10% - 90%
Options
Air filter, Ceiling mount, Document camera, Safety wire set, Soft carry case, Spare lamp, Suspension adapter
Loudspeaker
16 Watt
Room Type / Application
Large Meeting Room/Boardroom, Huddle space / Portable, Meeting room / Classroom
Positioning
Ceiling Mounted, Desktop
Colour
White
-
Warranty
36 months Carry in, Lamp: 36 months or 1.000 h (whichever comes first)
-
