Projector Colour

White

Loudspeaker

2 W

Noise Level -Normal

37 dB (A)

Noise Level -Economy

28 dB (A)

Options

Ceiling mount

Positioning

Ceiling Mounted

Power consumption -(Normal On-Mode)

284 W

Power consumption- (Eco On-Mode)

332 W

Power consumption -(Normal Peak-mode)

231 W

Power consumption -(Eco Peak-Mode)

0.3 W

Power consumption - (Energy saving standby)

181 W

Product Dimensions

302 x 252 x 92 mm (Width x Depth x Height)

Product Range

L1

Room Type / Application

Home Office

Single Unit

ZN

Supply Voltage

100 V - 240 V, 50 Hz - 60 Hz

Supported Humidity - Operation (from)

41 %

Supported Humidity - Operation (to)

95 %

Supported Humidity - Storage (from)

10 %

Supported Humidity - Storage (to)

90 %

Supported Temperature - Operation (from)

5

Supported Temperature - Operation (to)

35

Supported Temperature - Storage (from)

-10 °C

Supported Temperature - Storage (to)

60 °C

TCO Certified

No

LCD Panel (Type)

0.62 inches with

LCD Panel

C2 Fine

Projection System

3LCD Technology

Resolution

1080p

Android TV

No

Epson iProjection App

Ad-Hoc / Infrastructure

Google TV

No

Network Protocol

HTTPS

Network Protocol (Projector)

HTTPS

3D Colour Modes

n/a

3D Supported formats

n/a

Other features

A/V mute

Sealed Light Source Module - Yes

No

Sealed Light Source Module - IP5X rated

n/a

Sealed Optical Engine - Yes

No

Sealed Optical Engine - IP5X rated

n/a

Security (Visual product)

Kensington lock

Video Colour Modes

Cinema

Colour Light Output - Lumens

3400 Lumens

Colour Light Output - Luman (economy) in accodance with

2100 Lumens

Colour Light Output Testing Standard

In accordance with ISO 21118:2012

Colour Reproduction (Projector)

16.77 million colours

Contrast Ratio - Ratio:1

16000

High Definition

Full HD

Keystone Correction Type (Horizontal)

automatic

Keystone Correction Angle (Horizontal)

30

Keystone Correction Type (Vertical)

manual

Keystone Correction Angle (Vertical)

30

Lamp

6000 Hours Durability;12000 Hours Durability Eco

Light Source (Visual product)

Lamp

White Light Output - Lumens

2100 Lumens

White Light Output - Lumens (economy) in accodance with

2100 Lumens

White Light Output Testing Standard

In accordance with ISO 21118:2020

Interchangeable Lens

No

Lens (varies by lens)

n/a

Lens Shift (varies by lens)

n/a

Mechanical shutter

No

Offset

13

Offset - varies by lens

n/a

Projection Distance varies by lens

n/a

Projection Distance Wide varies by lens

n/a

Projection Distance Wide Tele from

1.35 m

Projection Distance Wide Tele to

1.64

Projection Distance Wide Tele screen size

60 inch screen

Projection Distance Wide Tele varies by lens

n/a

Projection Lens F Number from

1.58

Projection Lens F Number to

1.7

Projection Lens F Number varies by lens

n/a

Projection Lens Focal Length (From)

14.06

Projection Lens Focal Length (To)

16.82 mm

Projection Lens Focal Length (varies by lens)

n/a

Projection Lens Focus

Manual

Projection Lens Focus (varies by lens)

n/a

Screen Size from

31 in

Screen Size to

305 in

Screen Size varies by lens

n/a

Throw Ratio from

1

Throw Ratio to

1.21

Type of Zoom

manual

Zoom factor (from)

1

Zoom factor (to)

1.2
