Pure Wireless Screen Sharing

Share content instantly from laptops, tablets, and smartphones in high quality. Supports AirPlay, Miracast, Chromecast, and up to 4 simultaneous presenters.

Wireless Video Conferencing Integration

Connect wirelessly to room peripherals including cameras, microphones, and speakers. Fully compatible with Microsoft Teams, Zoom, and Webex platforms.

Secure & Scalable Connectivity

Dual-network architecture with advanced encryption ensures secure communication and stable performance. Designed for enterprise-grade collaboration environments.

HDMI Output : 1 × HDMI 19-pin Female Connector
Video Output Resolution : 3840 × 2160 @ 60Hz, 3840 × 2160 @ 30Hz, 1920 × 1080 @ 60Hz, 1280 × 720 @ 60Hz
Format Compliance : HDMI 1.4 / HDMI 2.0
Wireless Video Capacity : 1080p @ 60Hz (AirPlay, WirelessMedia App, Show-Me Button)
HDCP : HDCP 1.4 / HDCP 2.2
Audio Output : 1 × 3.5mm Audio Jack
LAN Ports : 2 × RJ45 (1000 Mbps / 100 Mbps)
USB Interface : USB 3.0 ×3, USB 2.0 ×1, USB Type-C ×2
Audio Input Support : AirPlay, Miracast, DLNA, Windows/Mac, USB/BT Speakerphone
Control Interface : 3.5mm Phoenix Terminal, RS232 Interface
On-Screen Layout : 4 Main Windows + 14 Thumbnail Windows
Simultaneous Connections : Up to 16 Devices
Frame Rate : 20–60 FPS
Latency : <100 ms (Min 20 ms)
Wireless Standard : Wi-Fi IEEE 802.11 a/g/n/ac
Frequency Band : 2.4 GHz & 5 GHz
Data Rate : Up to 1200 Mbps
Dimensions : 220 × 120 × 41 mm (220 × 120 × 145 mm with antenna)
Weight : 1.0 kg (2.20 lbs)
Operating Temperature : -20°C to 60°C
Humidity : 20%–90% (Non-condensing)
Power Supply : 12V DC / PoE (IEEE 802.3af)
Power Consumption : 10W (Max)

e-Hub Pro
